Round LED Disc Screen

A flat round panel for logo walls and hanging brand marks, available with a finished edge band or as a bare edge-to-edge surface.

Pixel pitch	P1.25 – P2.5
Size	Ø600 – 3,000 mm
Brightness	≥600 nits indoor, ≥5,500 nits outdoor option
Refresh	3,840 Hz
Service	Front, magnetic
Lead time	4 to 8 weeks

Request a quote Download specs

What you get with this model

Modules cut radially so the pixel grid stays square to the circle instead of stepping at the rim
Two edge options: a powder-coated band that hides the carcass, or an edgeless build where LED runs to the rim
Single or double sided — the double-sided build uses a shared carcass with two faces and one controller
Rear steel frame with four-point hang, or a stand-off kit for wall mounting
Resolution is quoted as the inscribed square, so you know what a 16:9 clip will actually do

The disc is the most-specified shaped screen after the sphere: a logo wall, a shop sign, a hanging brand mark. Edged or edgeless changes the price more than the pitch does.

Technical data

Specifications

Figures are for the stock configuration. Values change with size, pitch and environment — the quotation carries the final numbers.

Model	DSC-P1.86-1200
Pixel pitch	P1.25 / P1.5 / P1.86 / P2 / P2.5
Diameter	Ø600 to Ø3,000 mm standard
Type	Single sided or double sided
Resolution example	Ø1,200 mm at P1.86 → 645 × 645 px
Brightness	≥600 nits indoor, ≥5,500 nits outdoor option
Refresh	3,840 Hz

Edge	Banded or edgeless
Viewing angle	140° H / 140° V
Max power	800 W/m² indoor
IP rating	IP43 indoor / IP65 outdoor
Mounting	Four-point hang or stand-off wall kit
Warranty	3 years

Application

Where this one works

Same build, different mounting and content depending on the venue. Tell us the site and we adjust the structure and the pixel map.

Shop fascia and logo wall

Hanging mall banner

Bank and brand interior

Exhibition signage

FAQ

Practical questions

How is a non-standard shape priced?

By the number of module types it needs. A shape that can be built from six module types is far cheaper than one that needs forty, even when they cover the same area. We tell you the count before we quote.

Can the artwork be mapped properly onto the shape?

Yes, and the mapping project is part of the delivery. For most shapes that means a 2:1 or cylindrical unwrap; for compound forms we supply a baked UV map so your content team works in a normal video timeline.
